Everything posted by red750

  1. red750

    Farman F.120 family

    The Farman F.120 were a family of multi-engine monoplane aircraft designed and produced by the French aircraft manufacturer Farman Aviation Works. It was operated in a diverse range of purposes, including as a commercial airliner and as a military bomber aircraft. The F.120, which received the nickname of Jabiru after a Latin American stork, was a fixed-undercarriage monoplane powered by either two, three or four engines, depending on the variant. It featured an unusually broad chord, low aspect-ratio main wing and a relatively deep fuselage. The trimotor variant had the centerline engine mounted high, which gave the aircraft an unusual appearance. During the early 1920s, the Aero Club of France set out numerous rules and regulations for its commercial airplane contest of 1923. Shortly following their issuing, Farman set about the designing of a new commercial aircraft that would, so far as reasonably possible, entirely fulfil these regulations; they had been judged to be of importance of the prospective aircraft's market appeal as various aerial-navigation companies had, formally or otherwise, adopted these regulations as requirements for their own needs. Additionally, the company's design team pursued several other ambitions, including high reliability levels, good onboard comfort levels, favourable flying characteristics, while also being as economically efficient as possible. The F.121 or F.3X was the first version to fly, with four 180 hp Hispano-Suiza 8Ac V8 engines mounted in tandem push-pull pairs mounted on stub wings, however, this arrangement caused cooling problems for the rear engines and the F.120/F.4X version followed shortly afterwards, powered by three 300 hp Salmson Az.9 radial engines. Development continued and a single F.122, modified from an F.4X, was powered by a pair of 400 hp Lorraine 12Db engines. Two military versions were also built, the F.123 with two 450 hp Hispano-Suiza 12Hb V12s, or F.124 with two 420 hp Gnome et Rhône 9Ad Jupiter radial engines. The Farman F.120 was a multi-engine multirole monoplane aircraft. It was relatively well-furnished for the era, being able to routinely conduct night flights via equipment such as searchlights, landing flares, position lights, and general illumination. Various passenger conveniences were present, including individual electric heaters and relatively large glass windows for the passengers to view the landscape below. The electricity, used by the radio set, illumination, and heating, was supplied from wind-driven generators using compact propellers that could be drawn inside the fuselage when not in use. In comparison to most contemporary aircraft, the aircraft possessed greater manoeuvrability, possessed relatively high stability, ease of handling, and was relatively easy to land. Dependent on the variant of the aircraft, as many as four engines could be installed. No significant structural changes were required for those aircraft equipped with a different number of engines, such as the trimotor and twin-engined variants. Mid-flight access to the engine was provided via special doors, permitting inspection and even minor repairs to be performed by the crew. The four-engined model of the aircraft had sufficient power that it could still consistently climb even with a single engine out; even the twin-engined model could maintain stable flight on only a single operational engine. The main fuel tanks were housed within the wing, relatively far from the engines; up to two auxiliary fuel tanks could be installed within the engine nacelles, and would operate independently of the main tanks. The aircraft possessed relatively high fuel efficiency for the era. The F.120 was equipped with a relatively thick wing, possessing a span of 19 m (62.34 ft.) and a chord of 6 m (19.68 ft.) at its centre. Both the thickness and the chord of the wing decrease towards the tips. The supporting framework of the wing was entirely enclosed. Both the spars and struts formed V-shaped girders on either side of the fuselage. The undercarriage consists of two main wheels that were supported by a pair of vertical V-shaped members that joined with oblique steel tubing to connective with the base of the fuselage. The fuselage was internally divided into various sections; the foremost section contained the baggage compartment along with, after which and just forward of the wing, the cockpit. This cockpit provided two seats for its crew, typically comprising one pilot and an assistant. The centre of the fuselage was occupied by the passenger compartment, which had sufficient space for up to 12 passengers to travel on comfortabl e seats even with a central aisle. To the rear of the fuselage was the navigator's room, which was fairly sizable and provisioned with then-modern instrumentation, including a drift meter, compass, radio set, work table and map holder; adjacent to this room was the lavatory. Primary access to the interior was via a single sliding door, while multiple exits were provided across the aircraft to aid in emergency egress. On account of having an entirely unobstructed fuselage base, it was relatively straightforward to convert the aircraft into an armed military configuration, such as that of a bomber or a torpedo plane. Furthermore, its speed and manoeuvrability were sufficient that it could realistically engage in aerial combat despite its carriage of relatively heavy bomb loadouts. The presence of multiple independent engines and its reliability meant that the aircraft could be realistically used over the sea. Despite being most commonly seen in lists of ugliest aircraft, following its first flight in 1923, the F.120 won a French airliner competition, the 1923 Grand Prix des Avions de Transports and its 500,000 francs first prize, before seeing service with several European airlines. The F.120 was capable of carrying up to nine passengers, and served on Farman airline's route Paris-Brussels-Amsterdam, but also with Danish Air Lines between Copenhagen and Amsterdam. They served until the late 1920s. Variants F.120 A single engined biplane bomber, powered by a 280 kW (370 hp) Lorraine 12Da engine. First flown in 1924, only two F.120 bombers were built. F.4X The original designation of the F.120 Jabiru F.120 Jabiru Four transport monoplanes powered by 3x 220 kW (300 hp) Salmson 9AZ water-cooled radial engines. F.3bis A twin engined transport aircraft powered by 2x 300 kW (400 hp) Lorraine 12Db engines, 1 built. F.3X The original designation of the F.121 Jabiru prototype. F.121 Jabiru (Specifications below) Nine transport aircraft powered by 4x 130 kW (180 hp) Hispano-Suiza 8Ac engines, one also modified from a F.120 Jabiru. F.122 A single transport aircraft powered by 2x 300 kW (400 hp) Lorraine 12Db engines. F.123 A single three-seater bomber powered by 2x 300 kW (400 hp) Hispano-Suiza 12Hb engines. F.124 A single three-seater bomber powered by 2x 310 kW (420 hp) Gnome et Rhône 9Ad Jupiter engines. Farman 121 Jabiru (4 engine) Farman 120 Jabiru (3 engine) Farman 123 Bomber (2 engine)
  2. This is a direct link to the aircraft graveyards page: https://planehistoria.com/the-silent-witness-of-air-history-aircraft-graveyards/
  3. C5 USAF.mp4 MP4 file sent to me by email. No URL so I couldn't post in Media.
      • 2
      • Like
  4. The Moynet M 360 Jupiter was a small executive transport built in France in the 1960s. It had an unusual twin-push-pull, single-fuselage configuration. Two prototypes were produced, the second with more power and seating, but no sales resulted. Some civil propeller driven aircraft that have used one or more pairs of engines in push-pull configuration have been flying boats, with engines mounted above the wing and clear of spray. Others have had a pair of engines, one at either end of a pod fuselage with a tail unit mounted on a pair of booms, for example the Cessna Skymaster, the Adam A500 or the Rutan Voyager. The Moynet 360 Jupiter was an example of a push-pull aircraft of a less common configuration, where a single conventional fuselage has an engine at either end; the Dornier Do 335 fighter used the same arrangement. For light civil aircraft, the aim was to combine the performance of a conventional twin-engined aircraft with the ease of handling of a single-engined one. The Jupiter was an executive transport with between four and seven seats, depending on engine power. It was designed by André Moynet, a member of the National Assembly of France and a former government minister, while also a test-pilot, and built by S.S. Engins Matra (so it is sometimes referred to as the Matra Moynet Jupiter), the first prototype flying on 17 December 1963 with the designer and Lucien Tieles at the controls. Its wing had a straight trailing edge, but the centre section had strong taper on the leading edge which continued more weakly outboard. It was of two spar, stressed skin construction, carrying mass balanced ailerons and slotted flaps. The main undercarriage legs, placed at the end of the centre section each carried a single wheel and retracted inwards electrically. A retractable nosewheel completed the landing gear. One horizontally opposed Lycoming engine was conventionally placed in the nose. Behind it was a standard cabin, though the front seats were further ahead of the leading edge than usual because of the rearward shift of the centre of gravity caused by the rear engine. There were three large windows on each side. For the same reason the rear fuselage was quite short, and it lacked the normal taper, giving it a boxy look, so that the second, pusher Lycoming could be mounted in the extreme tail. This was cooled by air from rectangular intakes on the upper sides of the rear fuselage. The straight edged, tapered tailplane was mounted on the fuselage top above the engine, with small endplate fins carrying balanced rudders. These fins extended above and below the tailplane, with arrow shaped leading edges and straight, swept trailing edges. There was also a long, shallow strake over the rear fuselage. Seen from below, the long span of the tailplane was striking, about 44% of that of the wings; the elevators filled most of the outer part of its trailing edge, avoiding the propeller airstream. Only two Jupiters were built. The first, designated 360-4 and initially registered as F-WLKE had two 200 hp (150 kW) Lycoming IO-360-A1A engines driving two-bladed propellers and was configured as a 4-5 seater.
  5. The Piaggio P.23R, also known as the Piaggio P.123 for propaganda purposes, was an Italian commercial transport aircraft prototype designed and built by Piaggio. Unrelated to Piaggio P.23M. Piaggio designed the P.23R specifically to break speed records for commercial transport aircraft. It was a three-engine low-wing cantilever monoplane with twin tail fins and rudders. The three 671-kilowatt (900-horsepower) Isotta Fraschini Asso ("Ace") XI R V-12 engines were mounted in aerodynamically clean, sleek cowlings and each drove a three-bladed propeller. The fuselage was pencil-shaped. The crew of two sat side by side in separate open cockpits, each protected by a windscreen. The P.23R later was re-engined with three 746-kilowatt (1,001-horsepower) Piaggio P.XI RC.40 radial engines and its landing gear was modified. In addition, both cockpits were enclosed with canopies.
  6. The Piaggio P.23M was an Italian commercial transport aircraft prototype designed and built by Piaggio. Piaggio designed the P.23M specifically for flights across the North Atlantic Ocean, intending it to have potential for development as a commercial transport. It was a four-engine shoulder-wing monoplane with inverted gull wings and twin tail fins and rudders. To allow an easier landing if the aircraft had to ditch at sea, its fuselage was designed like a boat hull, which Piaggio termed an avion marin ("marine aviation") design, although the aircraft was not a flying boat. The main landing gear was retractable. The P.23M's four 671 kW (900 hp) Isotta-Fraschini Asso XI R. V-12 engines were mounted on the wings in two tandem pairs, each engine driving a two-bladed propeller; two of the propellers were mounted as pushers and the other two in a tractor configuration. Only one built.
  7. The Piaggio P.16 was an Italian heavy bomber designed and built by Piaggio for the Regia Aeronautica (Italian Royal Air Force). The P.16 was a three-engine shoulder-wing monoplane of mostly metal construction, with inverted gull wings. Its wing was thick and semi-elliptical, and its tail was mounted high on the fuselage. It had retractable main landing gear and a spatted, non-retractable tailwheel. In addition to bombs, its armament consisted of four 7.62-millimeter (0.3-inch) machine guns, of which two were mounted in the leading edge of the wing, one in a retractable dorsal turret, and one in the rear of the fuselage beneath the tail. The bombardier (bomb-aimer) manned a compartment set behind the nose engine on the underside of the fuselage. The P.16 first flew in November 1934, and an order for 12 aircraft was placed and then cancelled, with preference given to the Piaggio P.32, which was produced from 1936 to 1939.
  8. Archers have fixed gear. It's the Arrow with retractables.
  9. The Victa Aircruiser was a 1960s Australian four-seat touring monoplane designed by Henry Millicer and built by Victa. It was not put into production by Victa, and the rights were sold to AESL in 1969. Following the success of the earlier Airtourer, Millicer designed a four-seat version which he called the Aircruiser. The prototype registered VH-MVR first flew on 18 July 1966. Like the Airtourer it was a low-wing monoplane with a fixed nosewheel landing gear and powered by a 210 hp (157 kW) Continental IO-360-H piston engine. Rather than the sliding clear Perspex canopy of the Airtourer, the four-seat Aircruiser had a fixed cabin roof with a single "car type" door on the left hand side. Although Victa completed certification testing, no production of the Aircruiser followed, as Victa closed down its Aviation Division after failing to get financial assistance from the Australian government. Both Victa and Transavia Corporation had requested subsidies for Australian-designed and -built light aircraft, with Victa seeking a subsidy of up to 60% of the factory cost. Following the sale of the design rights of the Airtourer to Aero Engine Services Limited (AESL) of New Zealand, the rights to the Aircruiser were also sold to AESL in 1969. AESL's Chief Designer Pat Monk re-designed the aircraft as the AESL CT/4 Airtrainer, a fully aerobatic (+6G, -3G) military trainer. In 2013 Brumby Aircraft Australia announced the company had purchased the type certificate for the Victa Aircruiser to be developed into the Brumby Aircruiser.
  10. red750

    Grumman F2F

    The Grumman F2F was a single-engine, biplane fighter aircraft with retractable undercarriage, serving as the standard fighter for the United States Navy between 1936 and 1940. It was designed for both carrier- and land-based operations. Grumman's success with the two-seat FF-1, which was significantly faster than even the single-seat fighters of its time, resulted in a contract for the single-seat XF2F-1. Armed with two 0.30 in (7.62 mm) machine guns above the cowl, the new design also incorporated watertight compartments to reduce weight and improve survivability in the event of a water landing. The prototype first flew on 18 October 1933, equipped with the experimental 625 hp (466 kW) XR-1534-44 Twin Wasp Junior radial engine, and reached a top speed of 229 mph (369 km/h) at 8,400 ft (2,600 m) – 22 mph (35 km/h) faster than the FF-1 at the same altitude. Maneuverability also proved superior to the earlier two-seat aircraft. The Navy ordered 54 F2F-1 fighters on 17 May 1934, with the first aircraft delivered 19 January 1935.[citation needed] One additional aircraft (BuNo 9997) was ordered to replace one which crashed on 16 March 1935, bringing the total to 55, with the final F2F-1 delivered on 2 August 1935.[citation needed] The F2F-1 had a relatively long service life for the time, serving in front-line squadrons from 1935 to late 1939, when squadrons began to receive the F3F-3 as a replacement. By September 1940, the F2F had been completely replaced in fighter squadrons and was relegated to training and utility duties. The last F2F-1s were stricken from the list of naval aircraft in early 1943. Variants XF2F-1 United States Navy designation for the Grumman Model G-8 prototype with a 625 hp (466 kW) XR-1534-44 Twin Wasp Junior radial engine, one built F2F-1 Production variant with a 700 hp (522 kW) R-1535-72 Twin Wasp Junior radial engine, 55 built.
  11. The Hawk GafHawk ("General Aviation Freighter") was a small, turboprop-powered freighter aircraft developed in the United States in the 1980s but which only flew in prototype form. It was designed by Hawk International as a means of transporting drilling equipment in and out of remote locations, and was designed to be simple, rugged, and have good STOL and rough-field performance. The resulting design was a boxy aircraft with a rectangular-section fuselage with a high-set tail and rear loading ramp. The high aspect-ratio wings were high-set and braced with struts. The landing gear was fixed and of tricycle configuration, with the main units having dual wheels. Certification proved elusive, however, and Hawk eventually abandoned the project without building any other examples.
  12. Observers said he aimed for the trees to avoid school kids.
  13. A Jetstar passenger has been arrested at Melbourne Airport after forcing open a cabin door and jumping out of the plane. The drama unfolded on Thursday morning just after 10am when flight JQ507 arrived from Sydney. Jetstar confirmed to Yahoo News that the passenger exited the plane by deploying an emergency exit. "We can confirm that a passenger opened the emergency exit door after arrival into Melbourne, which automatically deployed the slide," a spokesperson said. The plane was parked at a boarding gate at the time. The reason behind the man's impulsive act is not currently clear, however, photos show the man clinging to one of the plane's engines before he landed on the tarmac. Ground staff were able to restrain the passenger before the Australian Federal Police intervened. The ground staff have since been praised for their swift response to the incident. "Melbourne Airport is proud of the exceptional response from ground crew, which meant there was no immediate danger to other passengers or airport staff," a spokesperson from Melbourne Airport said. Full report.
  14. The Conroy Skymonster (CL-44-0) is a 1960s United States specialized cargo aircraft based on the Canadair CL-44 freighter, with an outsize fuselage. The aircraft was designed by John M. Conroy as a transport aircraft that could be used to ferry three Rolls-Royce RB.211 jet engines from Belfast, Northern Ireland, to Palmdale, California, United States. The engines were to be installed on the Lockheed L-1011 TriStar airliner. The Skymonster was derived from a Canadair CL-44 freighter, in turn a derivative of the Bristol Britannia. It features an enlarged fuselage, like the Aero Spacelines Mini Guppy, which was produced by Jack Conroy's previous company, Aero Spacelines. The conversion was performed outdoors, under covered scaffolding, at the Santa Barbara California airport. The nose section was built using foam covered with fiberglass, while the larger fuselage was constructed using conventional aluminum structure. The Skymonster first flew on 26 November 1969, under the US registration "N447T". The CL-44 from which it had been converted also bore this same registration, and was previously operated by the Flying Tiger Line. Only one prototype was built. Another one was ordered, but the CL-44 on which it was to be based crashed before delivery. In 1970, the prototype was leased by Transmeridian Air Cargo, who gave it the name "Skymonster". Despite its being renamed "Bahamas Trader" later on, the name Skymonster stuck, and it is now commonly known as this. In 1978, it was bought by British Cargo Airlines. In 1982, it went to HeavyLift Cargo Airlines, who re-registered it with the Irish registration EI-BND. The aircraft went into storage in 1993, but was bought by a leasing company only two months later and leased to Buffalo Airways. According to Mikey McBryan General Manager for Buffalo Airways in Yellowknife Canada, this Buffalo Airways was a different operator and had no connection to the Canadian company. Its next lease was to Azerbaijan Airlines in 1997, under the registration 4K-GUP. In March 1998, it was leased to Baku Express. In August 1998 it went to First International Airlines and was registered 9G-LCA. In 1999, it was placed into storage, initially in the US, but then it was flown to Bournemouth Airport, UK, where it was scheduled to be scrapped. In December 2006 the aircraft was registered in the Philippines (RP-C8023) and was being prepared for service in Australia.[3] As of March 2008, the Skymonster was still at Hurn. In August 2008, it was reported that the aircraft was in the process of being scrapped, however as of September this was on hold amid further rumours about donation to a museum in Germany. On 14 January 2010, Bournemouth International Airport Limited offered the aircraft for sale in The London Gazette. After a long period of storage, activity was again seen around the Skymonster during the summer of 2013. In July 2013 it was registered N447FT in the United States to a Jordan Harlan Wayne, but has since been deregistered. As of 21 May 2021 the Skymonster remains at Bournemouth International Airport, moved from its original parking spot to make way for airport development.
  15. If you are using Windows, open the photo (say, Xxxxx) in Paint and click the rotate option, select left or right as required and Save As and label as Xxxxx 1.jpg. I use a photo editor, but the result is the same.
  16. Image rotate.
  17. Dornier Do K3 Crew: two Capacity: ten Length: 16.65 m (54 ft 7.5 in) Wingspan: 25 m (82 ft 0.25 in) Height: 4.55 m (14 ft 11.25 in) Wing area: 89 m2 (958.02 sq ft) Empty weight: 4,265 kg (9,403 lb) Gross weight: 6,200 kg (13,669 lb) Powerplant: 4 × Walter Castor radial piston engine , 227 kW (305 hp) each Performance Maximum speed: 230 km/h (143 mph, 124 kn) Range: 800 km (497 mi, 432 nmi)
  18. The Dornier Do K was a German commercial passenger and freight monoplane, designed by Claude Dornier and built by Dornier Flugzeugwerke. Only three prototypes of different designs were built and the type was not a commercial success. Do K1 The first Dornier Do K was the K1 which first flew on 7 May 1929. The K1 was a conventionally-braced high-wing monoplane, powered by a single nose-mounted 510 hp (380 kW) licence-built Bristol Jupiter VI radial engine, and had a conventional landing gear with a tailskid. The square-section fuselage had an enclosed cockpit for two with a cabin behind for freight or eight passengers. Test flights showed that performance was poor and the aircraft was redesigned. Do K2 The Do K2 flew in December 1929 with similar wings and fuselage but had a changed landing gear and four 240 hp (179 kW) Gnome-Rhone Titan radial engines. The four engines were strut mounted on each side of the fuselage in tandem pairs, one in tractor configuration and the other as a pusher. Although the aircraft had an increase in available power, the performance was little improved on the K1. Do K3 The K3 was a complete rethink of the design. The braced wing was replaced with a cantilever wing of larger span. The fuselage was changed to oval and stretched for two extra passengers and the tailskid was replaced with a tailwheel and the main units were enclosed in fairings. The four engines were in the same tandem arrangement as the K2, but located lower on the fuselage and changed to 305 hp (227 kW) Walter Castor radial engines. The performance was greatly improved but still provoked little interest and no others were built.
  19. Ligeti Stratos Further to page 6 entry, Powerplant: 1 × König SD 570 4 cylinder, 2 stroke, 21 kW (28 hp) Maximum speed: 200 km/h (120 mph, 110 kn) Cruise speed: 97 km/h (60 mph, 52 kn) Stall speed: 58 km/h (36 mph, 31 kn) Never exceed speed: 270 km/h (170 mph, 150 kn)
  20. Otto Celera 500L Cruise speed: 400 kn (460 mph, 740 km/h) estimated minimum Range: 4,500 nmi (5,200 mi, 8,300 km) Service ceiling: 30,000 ft (9,100 m) Maximum glide ratio: 22:1
  21. Scaled Composites Model 81 Catbird Maximum speed: 238 kn (274 mph, 441 km/h) Cruise speed: 218 kn (251 mph, 404 km/h) Rate of climb: 2,000 ft/min (10 m/s)
  22. red750

    Mitsubishi Ki-21

    The Mitsubishi Ki-21, formal designation "Type 97 Heavy Bomber" (九七式重爆撃機, Kyūnana-shiki jūbakugekiki) was a Japanese heavy bomber during World War II. It began operations during the Second Sino-Japanese War participating in the Nomonhan Incident, and in the first stages of the Pacific War, including the Malayan, Burmese, Dutch East Indies and New Guinea Campaigns. It was also used to attack targets as far-flung as western China, India and northern Australia. The Allies designated it under the reporting names "Sally" /"Gwen". In 1936, the Imperial Japanese Army Air Service issued a requirement for a new heavy bomber to replace both the Ki-20 (Army Type 92 Heavy Bomber) and the Ki-1 (Army Type 93 Heavy Bomber). The design called for a crew of at least four, top speed of 400 km/h (250 mph), endurance of at least five hours, and a bombload of 750 kg (1,650 lb). The design parameters were very ambitious for the mid-1930's; few twin-engine bombers anywhere in the world could exceed such performance at that time. Both Mitsubishi and Nakajima were asked to build two prototypes each, a further proposal from Kawasaki was rejected. The Mitsubishi design was an all-metal mid-wing cantilever monoplane with retractable landing gear, ventral bomb bay and two radial engines. The first prototype flew on 18 December 1936, with the second prototype, which differed in replacing the dorsal turret of the first prototype with a long greenhouse canopy, following later in the month. In the resulting competition, Mitsubishi's Ki-21 and Nakajima's Ki-19 were found to be similar, with the Ki-21 having better performance, while the Nakajima design was a better bombing platform and had more reliable engines. In order to make a final decision, two further prototypes were ordered from both Mitsubishi and Nakajima, with Mitsubishi instructed to change its own 615 kW (825 hp) Mitsubishi Ha-6 radial engines for the Nakajima Ha-5 engines used by the Nakajima design and vice versa, while the Ki-21 gained a revised glazed nose similar to that of the Ki-19 and revised tail surfaces. Thus modified, the Ki-21 proved superior and was ordered into production in November 1937 as the "Army Type 97 Heavy Bomber Model 1A". Production aircraft began to enter service in August 1938, supplementing and then replacing the Fiat BR.20 bombers which had been purchased as an interim measure. Several improved versions followed before the production of the type ended in September 1944. A total of 2,064 aircraft were built, 1,713 by Mitsubishi and 351 by Nakajima. Variants Ki-21 Prototype models with various engines and armament combinations for evaluation. Final version with Nakajima Ha-5 engine. 8 built Ki-21-Ia (Army Type 97 Heavy Bomber, Model IA) First production model, with 634 kW (850 hp) Nakajima Ha-5-kai engines. Most were built by Mitsubishi, 143 manufactured by Nakajima Ki-21-Ib (Army Type 97 Heavy Bomber, Model IB) Improved version with additional 7.7 mm (0.303 in) machine guns, larger bomb compartment and flaps, redesigned tail. 120 built by Mitsubishi, 351 (including Ki-21 Ib and Ic) by Nakajima Ki-21-Ic (Army Type 97 Heavy Bomber, Model IC) Improved type with one additional 7.7 mm (0.303 in) machine gun, increased fuel capacity, 160 built by Mitsubishi Ki-21-II Evaluation model with more powerful engines, 4 built Ki-21-IIa (Army Type 97 Heavy Bomber, Model IIA) Production model based on Ki-21-II, 590 built Ki-21-IIb (Army Type 97 Heavy Bomber, Model IIB) Final production version based on Ki-21-IIa with modified canopy, clear upper cabin replaced by rotating turret, 688 built. MC-20-I (Army Type 100 Transport, Model I) Unarmed civilian transport version, converted from Ki-21-Ia; approximately 100 aircraft were converted.
  23. The General Aircraft Limited GAL.49 Hamilcar or Hamilcar Mark I was a large British military glider produced during the Second World War, which was designed to carry heavy cargo, such as the Tetrarch or M22 Locust light tank. When the British airborne establishment was formed in 1940 by the order of Prime Minister Winston Churchill it was decided to develop a large glider which would be able to transport heavy equipment in support of airborne troops. General Aircraft Limited were chosen in January 1941 to develop this glider, which they designated the GAL.49 'Hamilcar'. It was designed to transport a light tank or two Universal Carriers. A number of problems, which included vacillation by the War Office on the number of gliders it wanted and poor management by GAL, led to delays in the production of the Hamilcar and it was not until mid-1943 that the first production glider was assembled. These problems were only partially solved and production of the glider continued to be slow, hampered by difficulties in finding suitable locations to store and construct them once their parts were produced. A total of 344 Hamilcars had been built when production ended in 1946. Hamilcars were used on three occasions,and only in support of British airborne forces. They first saw action in June 1944, when approximately thirty were used to carry Ordnance QF 17 pounder anti-tank guns, transport vehicles and Tetrarch light tanks into Normandy in support of British airborne forces during Operation Tonga. In September 1944 a similar number of Hamilcars were used to transport anti-tank guns, transport vehicles and supplies for airborne troops as part of Operation Market Garden. They were used a third and final time in March 1945 during Operation Varsity when they transported M22 Locust light tanks and other supplies. The gliders proved to be successful in all three operations, although their slow speed and large size made them easy targets for anti-aircraft fire, which resulted in a number of gliders being damaged or destroyed. A powered variant of the Hamilcar was produced, the Hamilcar Mark X, to extend the range of the Hamilcar so it could serve in the Pacific War; the conflict in the Pacific ended before the design could see combat. The Hamilcar was constructed primarily from wood, mainly birch and spruce, with fabric-covered plywood forming the skin, and high grade steel reinforcement beams in critical areas. It had a wingspan of 110 feet (34 m), a length of 68 feet (21 m) and a height of 20 feet (6.1 m) to the top of the fin with the tail down. It weighed 18,400 pounds (8,300 kg) when empty, and could transport a military load of 17,600 pounds (8,000 kg) to give a total weight of 36,000 pounds (16,000 kg). The whole aircraft was broken down into smaller sections for transport. It was so large and heavy that it required the largest and most powerful aircraft to pull it off the airfield and subsequently tow it; four-engined bombers were used, most frequently the Handley Page Halifax. Both wing and cockpit were set above the fuselage to provide the greatest amount of room for the cargo compartment, and to ensure that they did not interfere with the loading of vehicles; the compartment measured approximately 32 feet 31.5 inches (10.554 m), 7 feet 10.5 inches (2.400 m) inches wide and between 6 feet (1.8 m) and 7 feet 7 inches (2.31 m) inches in height. The nose of the glider was hinged and opened to the side for ease of loading vehicles and cargo, and the crew of two pilots were seated in tandem in a cockpit on the top of the fuselage, which was accessed via an internal ladder and was fifteen feet above ground; they were eventually protected by a bullet-proof windscreen and a plate of armour behind the second pilot. An intercom was also added to provide communication between the pilots and the personnel below them. An initial design feature, which was eventually removed prior to full-scale production, was the installation of an under-fuselage hatch which would allow the prone firing of a Bren light machine gun as the glider approached the landing zone. When the parts for a Hamilcar were completed and the glider was erected, it was flown to RAF North Luffenham in Rutland to have its specific cargo placed on board, and it was then flown to RAF Tarrant Rushton, which had been selected as the Hamilcar training and operational base in November 1943. It was not possible to tow the glider empty, so any empty gliders usually carried Universal Carriers or concrete blocks as ballast. For more information on the development, design, operational history and variants of the Hamilcar, click here.
  24. How is this likely to affect the ASIC
  25. The Otto Celera 500L is a business and utility light aircraft developed by American startup, Otto Aviation. By November 2021, 55 successful test flights had been completed, as introduction is targeted for 2024–2025. It has a single RED A03 diesel piston engine in a pusher configuration and can seat six passengers. It is named after the latin word for 'fast,' celer. Otto Aviation Group, LLC was established in 2008 by Bill Otto to develop the Celera 500L. William Otto has been a research scientist at Los Alamos Scientific Labs, systems engineer then chief scientist at North American Aviation. Otto Aviation is privately funded since 2008 and is seeking a Series B fundraising round: 200 million dollars are needed for FAR Part 23 certification in three years. Construction of the airplane commenced in 2015. The aerodynamic prototype made its maiden flight in January 2018, and began performance testing in September 2019. Otto publicly announced the aircraft and its development program in August 2020, and noted that 31 test flights had been flown to date.[6] By then, a weight-optimized conforming prototype with cabin windows and longer landing gear was expected to fly within 18 months. FAA certification and deliveries are targeted for 2023–2025. By March 2021, the prototype had achieved over 35 hours of flight tests, interrupted by the pandemic until Q3 2021, before two additional flying prototypes join the program. By October 2021, the company had raised more than $50 million. The prototype should reach a fuel economy of 30 mpg‑US (7.8 L/100 km) in cruise, to be improved with integrated heat exchangers replacing radiators nacelles. A second turbo-compressor should allow reaching a 38,000 ft (12,000 m) altitude, and a third for 50,000 ft (15,000 m). In 2022, Otto announced a partnership with ZeroAvia to build a hydrogen-powered version of its aircraft. Introduction planned 2024-2025.
×
×
