The Consolidated PB4Y-2 Privateer is an American World War II and Korean War era patrol bomber of the United States Navy derived from the Consolidated B-24 Liberator. The Navy had been using B-24s with only minor modifications as the PB4Y-1 Liberator, and along with maritime patrol Liberators used by RAF Coastal Command this type of patrol plane was proven successful. A fully navalised design was desired, and Consolidated developed a dedicated long-range patrol bomber in 1943, designated PB4Y-2 Privateer. In 1951, the type was redesignated P4Y-2 Privateer. A further designation change occurred in September 1962, when the remaining Navy Privateers (all having previously been converted to drone configuration as P4Y-2K) were redesignated QP-4B. The Privateer was externally similar to the Liberator, but the fuselage was longer to accommodate a flight engineer's station, and it had a tall single vertical stabilizer rather than the B-24's twin tail configuration. The Navy wanted a flight engineer crewmember to reduce pilot fatigue on long duration over water patrols. The single vertical tail was adopted from the USAAF's canceled B-24N design (and was slightly taller on the Privateer) because it would increase stability at low to medium altitudes for maritime patrol. The Ford Motor Company, which produced B-24s for the United States Army Air Forces, had earlier built an experimental variant (B-24K) using a single tail. Aircraft handling was improved. The single tail design was used on the B-32 Dominator and PB4Y-2 and was slated for the US Army Air Forces' proposed B-24N production model to be built by Ford, but that order (for several thousand bombers) was canceled on 31 May 1945. Defensive armament on the PB4Y-2 was increased to twelve .50-in (12.7 mm) M2 Browning machine guns in six power-operated turrets (two dorsal, two waist, nose and tail); the B-24's ventral, retractable Sperry ball turret was omitted. Turbosuperchargers were not fitted to the Privateer's engines since maritime patrol missions were not usually flown at high altitude, improving performance and also saving weight. For more details on development and operational history, click here. Variants. YPB4Y-2 prototypes, three built. PB4Y-2 (Specifications below) main production version, 736 built. PB4Y-2B PB4Y-2s equipped to launch ASM-N-2 Bat air-to-surface missiles. Redesignated P4Y-2B in 1951. PB4Y-2M PB4Y-2s converted for weather reconnaissance. Redesignated P4Y-2M in 1951. PB4Y-2S PB4Y-2s equipped with anti-submarine radar. Redesignated P4Y-2S in 1951. PB4Y-2G PB4Y-2s converted for air-sea rescue and weather reconnaissance duties with the U.S. Coast Guard. Redesignated P4Y-2G in 1951. PB4Y-2K PB4Y-2s converted to target drones. Redesignated P4Y-2K in 1951 and QP-4B in 1962.

The Short Shetland was a British high-speed, long-range, four-engined flying boat built by Short Brothers at Rochester, Kent for use in the Second World War. It was designed to meet an Air Ministry requirement (defined in Specification R.14/40) for a very-long range reconnaissance flying boat. The design used the company's experience with large scale production of the Short Sunderland. The end of World War II prevented the Shetland from entering production. It was the first aircraft designed with a 110 volt electrical system. Specification R.14/40 replaced an earlier specification R.5/39 which was an up-armed revision of specification R.3/38 for a faster flying boat than the Short Sunderland. Shorts, among others, had tendered a design for R.5/39 but the ministry had changed its mind about the need for an immediate replacement for the Sunderland. R.5/39 had considered a maximum weight up to 84,000 lb (38,102 kg) – R.14/40 allowed for a maximum takeoff of nearly 100,000 lb (45,359 kg) with a bomb load of 20,000 lb (9,072 kg). The projected engines were the Bristol Centaurus radial or the Napier Sabre inline. Shorts and the other British manufacturer of big flying boats, Saunders-Roe (Saro), were involved in the competitive tender for R.14/40; Saro proposed the Saunders-Roe S.41. Rather than selecting either company's design, the Air Ministry asked the companies to submit a combined project, stipulating the terms under which the work was to be shared between them. The detailed design was performed by Saro, its experience with the Saro Shrimp contributing to the hull shape, as well as building the wing. Shorts built the hull, tail and the final assembly. Variants Short S.35 Shetland I (Specifications below) The first prototype and what was to be the only Shetland I (Serial Number DX166) first flew on 14 December 1944, piloted by Shorts' chief test pilot John Lankester Parker as captain and Geoffrey Tyson as co-pilot. The aircraft flew without gun turrets (its role having been revised to that of unarmed transport before its maiden flight. It was delivered to the Marine Aircraft Experimental Establishment (MAEE) at Felixstowe in October 1945. Testing indicated satisfactory water handling but the stabilising floats were mounted too low and did not offer sufficient clearance for takeoffs with maximum load. Flight testing revealed problems with the harmonisation of controls and marginal longitudinal stability. Before the trials were complete, the aircraft burnt out at its moorings on 28 January 1946 as a result of a galley fire. Short S.40 Shetland II With the end of the war, the second prototype (Serial Number DX171) was completed as a civil transport and designated Shetland II. It was designed to carry 70 passengers but only 40 seats were fitted. Registered G-AGVD, the Shetland Mk.II's first flight took place on 17 September 1947. After trials, it was delivered to Short's factory at Belfast, but no orders were forthcoming and it performed only limited flight trials before being scrapped in 1951.

The Aerocar Mini-IMP (Independently Made Plane) is a light aircraft designed by Moulton Taylor and marketed for homebuilding by Aerocar International. It is a scaled-down derivative of his original Aerocar IMP design. A two-seat version called the Bullet was also built. The Mini-IMP follows the same unconventional layout as its larger predecessor, with a center mounted engine, long driveshaft to a tail propeller, and inverted-V rudder/elevators. The aircraft is available in the form of plans for amateur construction. Following Taylor's death, the plans and licensing for the Mini-IMP have been marketed by the Mini-IMP Aircraft Company of Weatherford, Texas. The aircraft features a cantilever high-wing, a single-seat enclosed cockpit, fixed or retractable tricycle landing gear or conventional landing gear and a single engine in pusher configuration. The aircraft is made from riveted aluminum sheet. Its 24.5 ft (7.5 m) span wing is mounted well behind the pilot and employs a NASA GA(PC)-1 airfoil. The engine is mounted behind the pilot's seat driving the propeller through an extension shaft. Engines used include the 60 to 100 hp (45 to 75 kW) Volkswagen air-cooled engine four-stroke. Taylor claimed the Mini-IMP was not an original design, but an updated version of the 1912 Edson Fessenden Gallaudet Bullet, a design that was capable of 110 mph in the earliest days of flight. In the late 1970s inquiries were made concerning a military version of the Mini-IMP, skinned with Kevlar, armed with two 7.62-millimeter machine guns, and with room in the baggage compartment for a considerable quantity of ammunition. Nothing came of the proposal.

The Bolkhovitinov DB-A (Dal'niy Bombardirovshchik-Akademiya – long-range bomber, academy) was a heavy bomber aircraft designed and built in the USSR from 1934. Bolkhovitinov became the head of the VVIA design group at the VVA Zhukovsky ( - VVS academy Zhukovsky ) tasked with the design of a replacement for the Tupolev TB-3 heavy bomber. The resulting DB-A was advanced for its day, with stressed skin aluminium alloy construction throughout with clean lines, neatly cowled engines and trousered main undercarriage legs, with fully retracting main-wheels and tail-wheel. The split flaps, undercarriage, nose turret and bomb-bay doors were all operated by a pneumatic system recharged by engine-driven compressors. Flight trials began on 2 May 1935 at Khodinka piloted by N.G. Kastanyev and Ya.N. Moseyev, factory tests were completed by April 1934 and NII testing was carried out in May and June 1935. The excellent performance demonstrated included, sustained flight at an altitude of 2,500 m (8,202 ft) with two engines shut down, and 4,500 km range. A decision was made to fly nonstop from Moscow to the US, and the DB-A was modified to fly, at an overload weight of 34,700 kg (76,500 lb), carry enough fuel to fly 8,440 km (5,244 miles). The red-painted DB-A prototype under command of Sigizmund Levanevsky departed Moscow Shchyelkovo airport on 12 August 1937 on an attempt to fly to Fairbanks, Alaska. After 14 hours, 32 minutes, the crew sent a radio message that one engine had failed and gave a revised ETA for Fairbanks, but nothing further was heard from the DB-A, and the fate of the aircraft and crew remains a mystery. A second aircraft with increased gross weight, improved airframe, re-designed nose and more power was completed and flown in March 1936 as the DB-2A. An order for 16 aircraft was placed late in 1937, with the designation DBA, but only twelve were completed due to the advent of the TB-7/Pe-8. Variants DB-A – The initial prototype aircraft, with M-34RN engines, lost on a nonstop flight Moscow to Fairbanks, Alaska. DB-2A – The second prototype with many detail improvements and M-34RNV engines. DBA – Production aircraft ordered in 1937. Sixteen aircraft ordered, but only twelve completed, with M-34FRN engines plus turbo-chargers, rearwards retracting main undercarriage, gunners cockpits in the rear of the inner engine nacelles, and other modifications. TK-1 TK ( - heavy cruiser) – Projected escort bomber with 11 crew, 3xShVAK + 3,000 rounds, 5xShKAS + 11,000 rounds and underwing rockets.

The Croses EC-6 Criquet ("Locust") is a 1960s French two-seat homebuilt aircraft designed by Emilien Croses. The EC-6 Criquet is a design for a homebuilt aircraft with a tailwheel landing gear, and tandem wing configuration similar to the Mignet Pou-du-Ciel family. It has two side-by-side seats. It first flew in 1965, and seven examples had flown by 1977, with more than 60 known to be under construction. The EC-6 Criquet Léger (Mini Criquet) is an ultralight variant. The LC-6 Criquet is an improved version developed by Gilbert Landray. The LC-10 Criquet was developed by a Mr Millet of Société Co-Plasud who used fibreglass construction throughout the entire aircraft. It was used as a trainer by the Aéro-Club du Maconnais. While considerably more expensive to build than a conventional wooden Criquet, the fibreglass version was also 80 kg (180 lb) heavier. As well as being used for local flying, the Criquet has been flown to both national and international light aircraft rallies. A French owned example visited the 1992 rally at RAF Wroughton airfield near Swindon, Wiltshire, England. Variants EC-6 Criquet (English:cricket) The original version designed by Emilien Croses. EC-6 Criquet Léger An ultralight version. LC-6 Criquet (LC - Landray-Coses) The EC-6 modified and improved by Gilbert Landray. LC-10 Criquet (LC - Laibie-Coses) An all fibre-glass version of the EC-6 built by M. Millet of Société Co-Plasud (president of the Aero-club de l'Aude). A second LC-10 was built by M. Barrière

The Shenyang FC-31 Gyrfalcon (Chinese: 鹘鹰; pinyin: Gǔ yīng), also known as the J-31 or J-35, is a Chinese prototype mid-sized twinjet 5th-generation fighter aircraft developed by Shenyang Aircraft Corporation (SAC). The official nickname published by SAC is "Gyrfalcon", though it has also been referred to as the "F-60" or "J-21 Snowy Owl" (Chinese: 雪鸮) in some media reports, or "Falcon Hawk" by some military enthusiasts. J-XX nomenclatures in the Chinese military are reserved for programs launched and financed by the People's Liberation Army, while the FC-31 plane was developed independently as a private venture by the aircraft manufacturer. While the Chengdu J-20 stealth fighter was officially endorsed by the People's Liberation Army Air Force after Chengdu Aerospace Corporation's proposal won the PLAAF bid for the next-generation jet fighter, Shenyang Aircraft Corporation pressed on and developed a private project aiming to secure potential export customers. A photo of a model labeled F-60 was posted on the Internet in September 2011. In June 2012, photos and phone camera video clips started to emerge on internet regarding a heavily overwrapped fighter plane airframe (widely suspected to be the F-60 prototype) being road-transferred on a highway, earning the nickname "the zongzi plane" (Chinese: 粽子机) among Chinese netizens, though some suspect it of merely being an L-15 trainer aircraft. Pictures of a possibly fully assembled aircraft parking on an airfield emerged on 15 or 16 September 2012. The F-60 is reported to be the export version, where the J-31 would be the domestic Chinese version of the same fighter. Chinese aviation expert Xu Yongling has called the J-31 an export-oriented low-end latest generation warplane. It is very likely that the J-31 will be inducted as a carrier-based naval fighter. In an interview with China's state-run media, FC-31's chief designer Sun Cong expressed that the aircraft would follow his J-15 onto China's aircraft carriers. However, officials from AVIC only said that the aircraft was intended for export as a competitor to the F-35. There has also been reports that the PLAN has urged Shenyang to develop a carrier-compatible version of J-31. In 2015, Jiangsu A-Star Aviation Industries Company marketed its EOTS-86 infra-red search and track as a possible addition to the J-31. An improved prototype, with modifications to the vertical stabilizers, wings, and airframe, an electro-optical targeting system, a larger payload, improvements in stealth, and upgraded electronics, made its maiden flight in December 2016. In November 2018, an Aviation Week article stated that the FC-31 program has received government funding and is being sought after by both the PLANAF and PLAAF, according to official sources. In June 2020, reports surfaced that a third variant of FC-31, albeit a more production-ready version with smoother lines, a bigger radome for a bigger radar, and a closer alignment of control surfaces to reduce the radar signature, had been developed. The "new fighter" has been referred to by some as J-35. On October 29, 2021, the modified carrier-based variant of the FC-31, dubbed J-35 by commentators, made its maiden flight. It is intended to operate from the forthcoming Type 003 aircraft carrier with an electromagnetic catapult system. The naval variant is based on the second prototype of the FC-31, but also includes a catapult launch bar and a folding wing mechanism. For further details, click here.

The Boeing L-15 Scout or YL-15 was a small, piston engine liaison aircraft built by Boeing in very small numbers after World War II. It was a short take-off and landing (STOL) aircraft powered by a 125 hp Lycoming engine. The L-15 was an attempt by Boeing to expand its product line as World War II drew to a close, and Boeing's production of combat aircraft declined. Boeing decided against marketing the L-15 as a general aviation aircraft, and the twelve that were produced went to the United States Army for testing, then were transferred to the United States Fish and Wildlife Service in Alaska for various duties. The scout was a conventional geared aircraft that was also tested on ski and float gear. The unique fuselage tapered sharply behind the pilot similar to a helicopter fuselage, with a high-mounted boom supporting the tail surfaces. The original design included a single vertical stabilizer, but two small downward-mounted stabilizers were used on production models. Spoiler-ailerons were used for roll control, and full length flaps were mounted on the trailing edge of the wings. The rear fuselage was all-window, and the tandem co-pilot could swivel the chair rearward. Although its cruise speed was only 101 mph, the aircraft was rated to be towed by another aircraft at speeds up to 160 mph.

The Supermarine Swift is a British single-seat jet fighter aircraft that was operated by the Royal Air Force (RAF). It was developed and manufactured by Supermarine during the 1940s and 1950s. The Swift featured many of the new jet age innovations, such as a swept wing. On 26 September 1953, a Swift F.4 piloted by Commander Mike Lithgow broke the world absolute speed record, reaching a speed of 737.7 mph (1,187 km/h). After a protracted development period, the Swift entered service as an interceptor aircraft with the RAF in 1954. However, due to a spate of accidents incurred by the type, the Swift was grounded for a time, and had a relatively brief service life. The problems with the Swift led to a public scandal surrounding the development and performance of the aircraft, harming the reputations of the British government, the RAF, and the British aircraft industry. Ultimately, the less problematic Hawker Hunter assumed much of the role intended for the Swift and only half as many Swifts were manufactured as had once been intended. A later photo reconnaissance variant of the Swift had resolved some of the teething problems, but that proved to be too late for it to regain favour. An advanced derivative of the Swift that was to be capable of transonic speeds, the Supermarine 545, was also under development during the early 1950s. However, it was cancelled in 1955, principally due to the poor performance of the Swift. During 1945, the Second World War came to a close and a new post-war Labour government, headed by Clement Attlee, came to power in Britain. The incoming Attlee government's initial stance on defence was that no major conflict would occur for at least a decade, and thus there would be no need to develop or to procure any new aircraft until 1957. In accordance with that policy, aside from a small number of exceptions such as what would become the Hawker Sea Hawk for the Royal Navy, the majority of Specifications issued by the Air Ministry for fighter-sized aircraft during the late 1940s were restricted to research purposes. Aviation author Derek Wood refers to this policy as being: "a fatal error of judgement which was to cost Britain a complete generation of fighters and heavy bomber aircraft". In part, the Swift had its origins in the experimental fighter prototypes that had been developed. Specifically, a number of Supermarine-built prototypes had been ordered under Specification E.41/46, which had sought the production of an experimental fighter aircraft furnished with a swept wing. The first of those prototypes was designated as the Type 510, which was heavily based on the straight-wing Supermarine Attacker, an early jet aircraft which was procured by the Fleet Air Arm (FAA) of the Royal Navy. The principal difference from the Attacker was that it had been modified with a swept wing configuration. During 1948, the Type 510 had conducted its maiden flight, a year after the first navalised prototype Attacker had flown. That flight made it the first British aircraft to fly with both swept wings and a swept tailplane. In trials for the Fleet Air Arm, the Type 510 was also the first swept-wing aircraft to take off from and land on an aircraft carrier. During the late 1940s, in the face of the emerging Cold War, the RAF came to recognise that it would urgently require the development and procurement of fighters equipped with features such as swept wings. That need was felt to be so pressing that it was willing to accept interim fighter aircraft while more capable fighters were being developed. In 1950, with the outbreak of the Korean War, Britain's heavy involvement in that conflict led to a flurry of orders being placed. In particular, the RAF felt that a pair of proposed fighter aircraft from Hawker Aircraft and Supermarine were of great importance and, in the same year, ordered the proposed fighters "off the drawing board". The Supermarine design was designated as the Type 541, and was essentially an advanced development of the earlier Type 510 experimental aircraft. For more details of development, design, operational history and variants, click here.

The Boeing MQ-28 Ghost Bat, previously known as the Boeing Airpower Teaming System (ATS), is a Loyal Wingman class stealth, multirole, unmanned combat aerial vehicle in development by Boeing Australia for the Royal Australian Air Force (RAAF). It is designed as a force multiplier aircraft capable of flying alongside crewed aircraft for support as part of an integrated system including space-based capabilities, and performing autonomous missions independently using artificial intelligence. The Ghost Bat is an uncrewed aerial vehicle incorporating artificial intelligence and utilising a modular mission package system in the nose of the aircraft. The entire nose section can be removed and quickly swapped for another with a different payload for various missions including combat, force reconnaissance and electronic warfare. Developed under Air Force Minor Program DEF 6014, one role will be to utilise the Manned-Unmanned Teaming (MUM-T) concept to support and protect manned Royal Australian Air Force (RAAF) aircraft, such as the F-35A, F/A-18F, E-7A, and KC-30A while they conduct operations. The UAV is designed to act as a "loyal wingman" that is controlled by a parent aircraft to accomplish tasks such as scouting or absorbing enemy fire if attacked, as well as operating independently. It has a 2000-mile ferry range or 900-mile combat radius. The UAV also has a jet engine which allows it to fly in the high subsonic flight regime and keep up with manned fighters. Boeing has said it has 'fighter-like' maneuverability. The MQ-28A prototype did not use any radiation-absorbent material (RAM) coating and instead relied on its shape to reduce its radar cross section (RCS). The aircraft wing is Boeing's largest resin-infused single composite component, leveraging proven technology from Boeing 787 wing's trailing edge. Three key manufacuring innovations were incorporated in the areas of robotic drill and fill, shimless assembly, and full-size determinant assembly. The aircraft is the first combat aircraft designed and developed in Australia in over half a century. In February 2019, Boeing said that it will "depend on the market" whether the aircraft is manufactured in Queensland or the US. Ghost Bat will remain a sovereign Australian program, with aircraft only being produced in Australia and the lead partner on the program being the RAAF. On 21 September 2021, Boeing Australia unveiled the launch of a new manufacturing facility for its Loyal Wingman uncrewed aircraft at Wellcamp Airport in Toowoomba, Queensland. On 4 November 2021, Boeing Australia announced the Melbourne facility had already commenced construction of its fifth aircraft whilst the new Towoomba facility is under construction. On 26 March 2024, Boeing Australia announced the start of construction on a 9000 square-meter facility to support construction of the Ghost Bat. The RAAF initially planned to buy three Airpower Teaming System (ATS) systems, as part of the Loyal Wingman Advanced Development Program (LWADP). The three drones were built at an automated production line in Melbourne, Victoria, a proof of concept for full-scale production. The order was increased to six with an A$115 million contract days after the first flight. As of 9 May 2023, the Australian government confirmed its commitment to funding 10 aircraft for the RAAF, not including three prototypes that will not be owned by the government or operated by the RAAF, taking the government’s total investment in the Loyal Wingman program to over A$600 million. The uncrewed platforms are scheduled to enter service with the RAAF in 2024-25. For testing and possible uses, click here.

The Franklin Sport is a two seat sport and training biplane built in the U.S. in 1930. Several different engines, in the power range 55–90 hp (41–67 kW), were fitted. Two remained airworthy in 2011. The Sport is a single bay, unequal span biplane. Its wings are built around twin spruce spars and, like the rest of the aircraft, fabric covered. Upper and lower wings have the same chord and outward-leaning, N-form interplane struts between their spars provide a wide interplane gap of about 50 in (1,300 mm). The upper wing is without dihedral but the lower, equipped with Frise ailerons, is set at 2°. Both wings are rectangular in plan out to rounded tips though the upper wing, held centrally over the fuselage on a cabane, has a semi-circular cut-out to increase the pilot's upwards field of view. All the Sport variants were powered by one of three types of five cylinder radial engine, nose-mounted on a frame which allowed easy exchanges between types. The fuselage has a flat-sided steel tube Warren girder structure with two open cockpits, one between the wings and the other just aft of the upper trailing edge with an extended, faired headrest. It is normally piloted from the rear seat, though the forward cockpit also has flight controls. Some instruments like the fuel gauge are visible from either seat. At the rear the tail also has a steel tube structure. The tailplane and elevators are mounted on top of the fuselage and the fin and unbalanced rudder have a rounded profile. The landing gear is fixed and of the split axle type, with mainwheels on V-struts from the central fuselage underside and with vertical oleo struts from the outer axle to the wing leading edges, where single bracing struts connect to the upper fuselage longerons. A short tailskid is mounted on the extreme rear fuselage. The Sport prototype, powered by a 55 hp (41 kW) Velie M-5 engine, first flew on 27 January 1930. After tests this was abandoned and production aircraft had either a 65 hp (48 kW) M-5 (Sport A, 8 built) or a 90 hp (67 kW) Lambert R-266 (Sport 90, 6 built) engine. The histories of most of these club aircraft is uncertain. Further production ended in 1933 when Franklin Aircraft ceased trading. Two, both Sport 90s, remained airworthy in U.S. museums in 2011, though only one was on public display. Variants Sport 55 1930, Prototype, 55 hp (41 kW) Velie M-5. One only. Sport 65 (Sport A) 1930, 65 hp (48 kW) M-5. Eight built. Sport 70 (Sport B) 1930, 70 hp (52 kW) Le Blond 5DE. Built but not flown. Sport 90 1931 90 hp (67 kW) Lambert R-266. Six built.

The Yakovlev Yak-141 (Russian: Яковлев Як-141; NATO reporting name "Freestyle"), also known as the Yak-41, is a Soviet supersonic vertical takeoff/landing (VTOL) fighter aircraft designed by Yakovlev. Intended as a replacement for the Yak-38, it was designed as a supersonic fleet defence fighter capable of STOVL/VTOL operating from Soviet carriers. Four prototypes were built before the project's cancellation. Yakovlev always believed the Yak-38 to be an interim aircraft, developed to gain experience designing and developing military VTOL aircraft. Even before the Yak-38's introduction, the Soviet Navy desired a more comprehensive aircraft, with greater capabilities than the Yak-38 offered. The result was a design contract offered to Yakovlev in 1975. The requirement was for an aircraft with only one mission: air defense of the fleet. Unlike the Yak-38, this aircraft was to have sustained supersonic speed. Maneuverability, radar and weapons loads were expected to be similar to those of current front-line fighters, such as the Su-27 and MiG-29. For the Soviet Navy this aircraft was to be their next generation VTOL fighter. For Yakovlev the aircraft was viewed as a way of returning to designing Soviet fighter aircraft. Because of the importance and complexity of the project, Alexander Sergeyevich Yakovlev assigned a large portion of his OKB to the development of the new VTOL fighter, with no fewer than ten chief engineers working simultaneously on what was called "Product 48" (the military had designated it Yak-41). Over fifty designs were studied. One key problem was designing an aircraft with both vectoring thrust and an afterburner, which was essential for sustained supersonic speeds. A twin-engine design was considered, but abandoned as the loss of an engine on landing would result in an immediate roll to the side. Eventually it was decided that the best arrangement was a single vectoring nozzle located just behind the center of gravity, as well as dedicated vertical thrust jets positioned just behind the cockpit. A considerable amount of time was spent in the development of a flat, rectangular nozzle similar to that later employed on the American F-22 Raptor. Such a nozzle proved well-suited for the changes in configuration needed for both thrust vectoring and supersonic flight, and allowed for a thin, shallow tail. Ultimately, a circular nozzle was used, located between twin booms supporting the twin-finned tail. Yak-41 or Yak-141 The design was initially designated the Yak-41M by the Soviet military. Once testing commenced, and the two prototypes began accumulating numerous world class records, it became necessary to invent a designation for use in the west, as the name Yak-41M was classified. The designation Yak-141 was selected, and it was by this name that the aircraft became known to western allies, though officially the aircraft's designation remained Yak-41M within the Soviet military. In 1991 Lockheed-Martin entered into partnership with Yakovlev to further develop an aircraft they had always known as the Yak-141. Largely as a result of this agreement, by 1992 Yakovlev changed the aircraft's designation to Yak-141 for the two flyable prototypes. Series production in Russia could further change the designation. Four were built. For more details of design and development, operational history and variants, click here.
